Imaging Case of the Week 46

The following wrist x-rays are from a 30 year old man who has presented after a FOOSH injury to his wrist. What can you see?

wrist x-ray AP

click to enlarge

wrist x-ray lateral

click to enlarge

[peekaboo_link name=”Answer”]Answer[/peekaboo_link] [peekaboo_content name=”Answer”]

The AP view of the wrist shows a screw placed in the scaphoid (scaphoid fracture from previous injury). But the carpal bones appear quite crowded as they should normally have a distance of 1-2 mm between them.

The lateral view shows a peri lunate dislocation. The capitate with its distal bony attachments is lying posterior to the lunate.

Perilunate dislocation

click to enlarge

Thanks to John Larkin for the images.
